Forma Batten 10"

A roll-formed batten panel that delivers a board-and-batten style at a 10" coverage. It is an economical 26ga option for homes, garages and outbuildings that want the batten look in a solid colour.

Custom Made to Order – made to your project lengths by Calgary-based Pillars Metal. Starting at $4.57 / linear ft.

Forma Batten 10" features

• 10" coverage – about 0.83 sq ft per linear ft
• Roll-formed batten profile
• 26ga in standard colours
• A cost-effective board-and-batten alternative

Specifications

• Available gauges: 26ga
• Available finishes: Colour
• Coverage: 10" coverage (1 linear ft covers approx. 0.83333 sq ft)
• Applications: exterior wall cladding
• Best for: garages, sheds, cabins and residential exteriors

Pricing, lead time and delivery

$500 minimum custom material order. Estimated lead time: 2–3 weeks. Final pricing depends on profile, gauge, colour/finish, panel length, quantity, fabrication, trims, accessories, freight/delivery and project requirements. We deliver across Alberta; freight is quoted separately and GST is added at quoting.

Forma Batten 10" FAQ

How much does Forma Batten 10" cost?

Forma Batten 10" starts at $4.57 / linear ft. For example, 8 panels at 17'6" is 140 linear ft; at $4.57 per linear ft that is $639.80 in material, before GST and delivery.

How many linear feet of Forma Batten 10" do I need?

Each linear foot covers about 0.83333 sq ft, so 1,000 sq ft of wall or roof needs roughly 1,201 linear ft before waste, overlaps and openings. Send us your dimensions or plans and we'll calculate exact quantities for you.

How do I order Forma Batten 10"?

Use the Request a Quote form with your profile, gauge, colour, dimensions and postal code. We'll confirm quantities, trims, pricing and delivery – usually within one business day.

Request a Quote for final project pricing. Not sure how much material you need? Send us your dimensions, plans or photos and we'll calculate it for you.
